Max Heating Volume (m³) 502
Nominal Efficiency (kW) 22,1
Min Power (kW) 5
Nominal Power Water (kW) 18,8
Min Power To Water (kW) 4,3
Nominal Power (%) 89,2
Reduced Power Output (%) 94
Max Pellet Consumption (kg/h) 5,1
Min Pellet Consumption (kg/h) 1,1
Capacity Deposit Pellets (Kg) 45
Nominal Voltage (V) 230
Electrical Frequency (Hz) 50
Max Gas Temperature (ºC) 153,40
Min Gas Temperature (ºC) 66,05
Max Pressure (bar) 3
Weight (kg) 219
Chimney Diameter (mm) 100
Needed Depression In The Fireplace (pa) 12
Maximum Noise Level (Db) 49,1
Autonomy Min/Max (h) 8,8 - 40,9
Efficiency 93,8 %
Rated power 22,1 kW
Autonomy deposit min-max 8,8 - 40,9 h
